Variable speed gearmotor - VARIMOT

Speed 50Hz [r/min]: 1456 / 17 - 87
Speed 60Hz [r/min]: 1762 / 21 - 105
Total ratio [i]: 21,81
Output torque 50Hz [Nm]: 315 / 210
Output torque 60Hz [Nm]: 260 / 173
Ma max [Nm]: 450
Mounting position: M1A
ISO code: CLP 220
Lubricant type: Miner.Oil
Lubricant volume [l]: 0,80
Ratio range [1:]: 5.
:KWB_9999 KWB_0316
Motor power [kW]: 2.2 / 2.2
Motor power [HP]: 3.0 / 3.0
Cyclic duration factor S1-S10: S1
Multi range-voltage 50Hz [V]: 220-230 delta / 380-400 star
Nominal current [A]: 8,40 / 4,85
Multi range-voltage 60Hz [V]: 254-266 delta / 440-460 star
Nominal current [A]: 7,40 / 4,30
motor frequency A [Hz]: 50
motor frequency B [Hz]: 60
cos phi: 0,76 / 0,73
Thermal cl.[°C]/Enclosure[IP]: 155(F) / 66
Service factor motor: 1.15
International efficiency class: IE3
Efficiency 50 Hz: 86,7
Efficiency 60 Hz : 89,5
Design specification : Europe (CE)/USA (UR)/Canada (CSA)
K.V.A.code: M
Design: NEMA A
Ambient temperature min. [°C]: -20
Ambient temperature max. [°C]: 40
CT speed range: 300-1800RPM

Denron Industrial

SEW Eurodrive KA47 D26B DRN100LM4/DH Gearmotor

$1,245,180.00

Variable speed gearmotor - VARIMOT

Speed 50Hz [r/min]: 1456 / 17 - 87
Speed 60Hz [r/min]: 1762 / 21 - 105
Total ratio [i]: 21,81
Output torque 50Hz [Nm]: 315 / 210
Output torque 60Hz [Nm]: 260 / 173
Ma max [Nm]: 450
Mounting position: M1A
ISO code: CLP 220
Lubricant type: Miner.Oil
Lubricant volume [l]: 0,80
Ratio range [1:]: 5.
:KWB_9999 KWB_0316
Motor power [kW]: 2.2 / 2.2
Motor power [HP]: 3.0 / 3.0
Cyclic duration factor S1-S10: S1
Multi range-voltage 50Hz [V]: 220-230 delta / 380-400 star
Nominal current [A]: 8,40 / 4,85
Multi range-voltage 60Hz [V]: 254-266 delta / 440-460 star
Nominal current [A]: 7,40 / 4,30
motor frequency A [Hz]: 50
motor frequency B [Hz]: 60
cos phi: 0,76 / 0,73
Thermal cl.[°C]/Enclosure[IP]: 155(F) / 66
Service factor motor: 1.15
International efficiency class: IE3
Efficiency 50 Hz: 86,7
Efficiency 60 Hz : 89,5
Design specification : Europe (CE)/USA (UR)/Canada (CSA)
K.V.A.code: M
Design: NEMA A
Ambient temperature min. [°C]: -20
Ambient temperature max. [°C]: 40
CT speed range: 300-1800RPM
