Key Features & Specifications

• Enclosure

  • Full 304/316 stainless steel weatherproof ventilated enclosure

  • Overall dimensions: 60” (H) × 42” (W) × 12” (D)

  • Designed for harsh outdoor and coastal environments

• Motor Control

  • (4) WEG NEMA Size 4 motor starters

  • (4) individually mounted molded-case circuit breakers, one per starter, providing motor protection and local isolation

  • (4) WEG overload relays, one per contactor, for thermal motor protection

• Power Distribution & Protection

  • Molded-case main circuit breaker supplying and isolating all downstream sub-breakers

  • Proper coordination between main and branch protection devices

• Control & Automation

  • WEG PLC500 installed to:

    • Support all existing alarm and control logic from the previous system

    • Allow for future system expansion and additional control features

  • Control wiring clearly labeled and documented for maintenance and upgrades

• Operator Interface & Field Controls

  • Weatherproof, surface-mounted controls including:

    • Rotary switch for surrounding lighting control

    • Pilot lights to indicate operation and fault status

    • Manual / Automatic selector switch for pump operation

• Panel Utilities & Maintenance

  • Interior panel lighting for safe nighttime or low-light maintenance

  • Clean internal layout for ease of troubleshooting and servicing
